| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Output Voltage | |
| Package / Case | |
| Power (Watts) | |
| Storage Temperature | |
| Temperature Coefficient | |
| Type | |
| Voltage | |
| Width |
The Aimtec AME60-12SMJZ is a 60 Watt AC-DC converter designed for board mount applications. It operates with a universal input voltage range of 90-264 VAC or 122-370 VDC, making it suitable for global use.
This converter provides a single output of 12V at a maximum current of 5A, delivering a total power of 60W. Key electrical specifications include an efficiency of up to 86% at 230VAC, line regulation of ±0.5%, and load regulation of ±1%. It offers an adjustable output voltage range of ±10% and features continuous short circuit protection with auto-recovery.
The AME60-12SMJZ is housed in a 6-DIP module package and is designed for through-hole mounting. It operates within a temperature range of -40°C to 70°C with derating and has dimensions of 109.0mm x 58.5mm x 30.0mm. The unit provides 4000 VAC I/O isolation.
This converter is suitable for ITE (Commercial) applications and carries CE and cURus approval agency certifications. It includes features such as adjustable output and universal input, enhancing its versatility in various electronic designs.
The input voltage range is 90-264VAC (47-63Hz) or 122-370VDC.
The output voltage is 12V DC.
The maximum output current is 5A.
The operating temperature range is -40°C to +70°C (with derating).
The package is a 6-DIP Module with through-hole mounting.
Typical efficiency is 86% at 230VAC full load.
It includes over current protection (≥110% of Iout), over voltage protection (Zener diode clamp), and short circuit protection (continuous, auto recovery).
