| Category | |
| Manufacturer Name | |
| Applications | |
| Current | |
| Efficiency | |
| Features | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Power (Watts) | |
| Standard Number | |
| Type | |
| Voltage |
The Aimtec AME40-5SVZ-ST is an enclosed AC/DC converter designed for ITE (Commercial) applications. It delivers a 5V output with a maximum current of 8A, providing a total power of 40W. The converter features a universal input voltage range of 85-264 VAC or 100-370 VDC, making it suitable for global use.
With an efficiency of 82%, the AME40-5SVZ-ST operates within a temperature range of -40°C to 70°C with derating. It offers 4kV of isolation voltage and is designed for chassis mounting. The dimensions are 135.1mm x 70.1mm x 33.5mm.
This series, AME40-VZ, adheres to the 62368-1 standard. It is suitable for various commercial applications requiring a reliable power supply.
Key specifications include a 5V output, 8A current, 40W power, 82% efficiency, and a wide input voltage range.
The output voltage is 5V and the output current is 8A.
The input voltage range is 85 to 264 VAC or 100 to 370 VDC.
The power rating is 40W.
The operating temperature range is -40°C to 70°C with derating.
The efficiency is 82%.
The isolation voltage is 4kV.
The mounting type is chassis mount and the package style is enclosed.
