| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Power (Watts) | |
| Type | |
| Voltage | |
| Width |
The Aimtec AME3-5SCJZ is a 3W AC/DC converter designed for board-mount power supply applications. It delivers a nominal 5V output with a maximum output current of 600mA.
The converter accepts a wide input voltage range of 85-264 VAC or 100-370 VDC. It features a typical efficiency of 74% at 230 VAC and provides 3000 VAC input-to-output isolation.
This component is suitable for applications requiring a compact, isolated power supply solution. The AME3-5SCJZ is categorized under AC DC Converters within the Power Supplies - Board Mount category.
The nominal output voltage is 5V.
The maximum output current is 600mA.
The input voltage range is 85-264 VAC or 100-370 VDC.
The rated isolation voltage is 3000 VAC.
The power rating is 3W.
