The Aimtec AME3-3.3SBAZ is an enclosed AC DC converter designed for ITE (Commercial) applications. It provides a single 3.3V output at a maximum current of 700mA, delivering up to 2.31W of power.
This converter features a wide input voltage range of 90-528 VAC or 130-745 VDC, making it versatile for various power systems. Key electrical specifications include a typical efficiency of 61% at full load (115 VAC), ±5% voltage accuracy, ±3% line regulation, and ±5% load regulation. The output noise and ripple are kept to a maximum of 200mV p-p.
Designed for reliability, the AME3-3.3SBAZ operates within a temperature range of -40°C to +80°C, with derating applied at higher temperatures. It includes over-load and short-circuit protection with auto-recovery. The unit is isolated to 3000 VAC with an isolation resistance greater than 1000 MΩ.
Packaged in a 4-DIP module, this converter is designed for Through Hole mounting. Its dimensions are 35.6mm x 23.3mm x 19.3mm, and it weighs 25g. The case is constructed from plastic resin and fiberglass.
The nominal output voltage is 3.3V.
The input voltage range is 90-528 VAC at 47-440Hz or 130-745 VDC.
The operating temperature range is -40°C to +80°C.
It uses a 4-DIP through-hole module.
Yes, it has continuous short circuit protection with auto-recovery.
The input-to-output isolation voltage is 3000 VAC.
