The Aimtec AME25-48SJZ is a 25 Watt AC-DC converter designed for reliable power conversion in various applications. It operates with a wide input voltage range of 85-305 VAC (47-63 Hz) or 100-430 VDC, making it versatile for global use.
This converter provides a single output of 48V with a maximum current of 0.5A, delivering up to 25W of power. Key electrical specifications include a typical efficiency of 87%, voltage accuracy of ±2%, and line/load regulation of ±0.5% and ±1% respectively. It also features low ripple and noise (100 mV p-p) and a hold-up time of 80 ms at 230 VAC.
Designed for ease of integration, the AME25-48SJZ has a 6-DIP Module package and Through Hole mounting type. Its dimensions are 70.0mm x 48.0mm x 23.5mm. The operating temperature range is -40°C to +70°C with derating, and it offers robust protection features including over-current and short-circuit protection with auto-recovery.
Safety and reliability are ensured through 3000 VAC I/O isolation and a typical MTBF of over 300,000 hours. The unit is compliant with RoHS3 standards and has an MSL rating of 1.
85-305 VAC (47-63 Hz) or 100-430 VDC.
Output voltage is 48 V nominal, output current is 0.5 A maximum.
87% typical at 230 VAC.
-40°C to +70°C with derating.
6-DIP through-hole module.
Isolation voltage is 3000 VAC input to output, 2000 VAC input to ground.
Over current protection (≥110% of Iout), over voltage protection, and short circuit protection with auto recovery.
