| Category | |
| Manufacturer Name | |
| AEC Qualified | |
| Applications | |
| Approval Agency | |
| Automotive Grade | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Industrial Grade | |
| Input Voltage | |
| Length | |
| Medical Grade | |
| Military Grade | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Output Voltage | |
| Power (Watts) | |
| SVHC Present | |
| Type | |
| Voltage | |
| Width |
The Aimtec AME25-24SVZ-ST is an enclosed AC/DC converter designed for various applications. It offers a nominal output voltage of 24V and a maximum output current of 1.1A, providing a total power output of 26W. The converter accepts a wide universal input voltage range from 85 to 264VAC.
Key electrical specifications include an efficiency of 85% at 230VAC, an isolation voltage of 4000VAC, and a typical ripple and noise level of 50mV p-p. The operating temperature range is -40°C to 85°C, ensuring reliable performance in diverse environments. The unit also features output short circuit, over-current, and over-voltage protection.
Mechanically, the AME25-24SVZ-ST has dimensions of 96.1mm in length, 54.0mm in width, and 32.0mm in height. It is designed for chassis mounting. The converter meets CISPR32/EN55032 Class B EMI performance standards and is certified to IEC62368, UL62368, and EN62368 safety standards, making it suitable for ITE (Commercial) applications.
The output voltage is 24V.
The maximum output current is 1.1A.
The power rating is 26W.
The input voltage range is 85-264VAC.
The operating temperature range is -40°C to 85°C.
The isolation voltage is 4000VAC.
Yes, its EMI performance meets CISPR32/EN55032 CLASS B.
