| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Input Voltage | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Output Voltage | |
| Power (Watts) | |
| SVHC Present | |
| Standard Number | |
| Type | |
| Voltage | |
| Width |
The Aimtec AME25-24S277VZ-ST is an enclosed AC-DC power supply module designed for various applications including ITE (Commercial). It offers a universal input voltage range of 85-305VAC and provides a regulated 24V output with a maximum current of 1.1A, delivering up to 26W of power.
Key electrical specifications include an efficiency of 85% at 230VAC and an isolation voltage of 4000VAC. The operating temperature range is -40°C to 85°C, with derating applied at higher temperatures. Protection features such as output short circuit, over-current, and over-voltage protection are standard.
This converter is chassis mountable and has dimensions of 96.0mm x 54.1mm x 32.0mm. It is suitable for applications requiring reliable power conversion in demanding environments.
The converter accepts a universal input voltage range of 85-305VAC at 47-63Hz, or 100-430VDC.
It provides a nominal 24V DC output capable of delivering up to 1.1A continuously.
The unit features 4000VAC tested isolation voltage between the input and output circuits.
The device operates within a temperature range of -40°C to 85°C, with power derating applied at higher temperatures.
This enclosed power supply is designed specifically for chassis mounting applications.
The converter achieves a typical efficiency of 85% when operated at a 230VAC input.
The chassis mount package measures 96.0mm in length, 54.1mm in width, and 32.0mm in height.
