The AME25-15SMJZ is a compact board-mount AC/DC power supply module manufactured by Aimtec. Designed for industrial and commercial applications, it converts a wide input voltage range of 85 to 264 VAC or 100 to 370 VDC into a regulated 15 VDC output. The unit delivers up to 25 watts of continuous power with a maximum output current of 1.6 amperes.
Electrical performance is optimized for reliability, achieving 88 percent efficiency at 230 VAC input. Input current draw is rated at 0.6 amperes under 115 VAC conditions and 0.34 amperes at 230 VAC. The converter maintains strict output stability with line regulation of ±0.5 percent and load regulation of ±1 percent. Output ripple and noise are kept within 50 to 100 millivolts peak-to-peak when measured across a 20 MHz bandwidth.
Additional design considerations include a maximum hold-up time of 15 milliseconds at 115 VAC input and a maximum capacitive load rating of 4,000 microfarads. Standby power consumption remains minimal at less than 0.1 watts under no-load conditions, while leakage current is limited to 0.1 milliamperes. These characteristics make the module suitable for space-constrained equipment requiring efficient and stable DC power distribution.
The AME25-15SMJZ accepts an input voltage range of 85 to 264 VAC at 47-440 Hz, or 100 to 370 VDC.
The converter provides a maximum output current of 1.6 amperes at 15 volts.
Output ripple and noise measure between 50 and 100 millivolts peak-to-peak across a 20 MHz bandwidth.
The module maintains output for 15 milliseconds at 115 VAC input before shutting down.
The power supply can drive a maximum capacitive load of 4,000 microfarads.
