| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Height | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Power (Watts) | |
| Standard Number | |
| Storage Temperature | |
| Temperature Coefficient | |
| Type | |
| Voltage | |
| Weight | |
| Width |
The Aimtec AME25-15SJZ-ST is a 25 Watt AC-DC converter designed for ITE (Commercial) applications. It features a single output of 15V with a maximum current of 1.6A.
This converter operates with an input voltage range of 85-305VAC or 100-430VDC and boasts an efficiency of 84%. Key electrical specifications include ±2% voltage accuracy, ±0.5% line regulation, and ±1% load regulation. It provides 3000VAC isolation between input and output and 2000VAC from input to ground, with an isolation resistance greater than 1000 MΩ.
The unit is enclosed and designed for chassis mounting. Its dimensions are 96.0mm x 54.1mm x 32.0mm. The operating temperature range is -40°C to 70°C with derating, and it has a maximum case temperature of 100°C. It also includes over-current and over-voltage protection features.
The Aimtec AME25-15SJZ-ST provides a single output of 15V with a maximum current of 1.6A.
The maximum output wattage for the AME25-15SJZ-ST is 25W.
The input voltage range is 85-305VAC at 47-63Hz, or 100-430VDC.
The efficiency is 84% at 230 VAC input.
The operating temperature range is -40°C to 70°C, with derating.
This converter is designed for chassis mounting.
