| Category | |
| Manufacturer Name | |
| Applications | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Input Voltage | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Power (Watts) | |
| Standard Number | |
| Storage Temperature | |
| Temperature Coefficient | |
| Type | |
| Voltage | |
| Weight | |
| Width |
The Aimtec AME25-12SMJZ-ST is a 25 Watt AC-DC converter designed for versatile power supply applications. It accepts a wide input voltage range of 85-264 VAC at 47-440 Hz, or 100-370 VDC.
This converter provides a single 12V output with a maximum current of 2.1A. Key electrical specifications include a typical efficiency of 88% at 230VAC, voltage accuracy of ±2%, line regulation of ±0.5%, and load regulation of ±1%. The device offers 4000 VAC I/O isolation and a continuous short circuit protection.
With a chassis mountable design, the AME25-12SMJZ-ST has dimensions of 96.0mm x 54.1mm x 32.0mm. It operates within a temperature range of -40°C to 70°C (with derating) and is suitable for applications requiring a 60601-1 standard, such as medical equipment.
Features include over-current protection at 110% of Iout and a protection class of Class II. The converter is built with a heat-resistant plastic case compliant with UL 94V-0 flammability.
85-264 VAC (47-440Hz) or 100-370 VDC.
Enclosed chassis mount package.
-40°C to +70°C (with derating).
12V nominal output, 2.1A maximum current, 25W maximum power.
88% typical at 230VAC.
4000 VAC.
96.0mm x 54.1mm x 32.0mm (3.78" x 2.13" x 1.26").
