| Category | |
| Manufacturer Name | |
| AEC Qualified | |
| Applications | |
| Approval Agency | |
| Automotive Grade | |
| Current | |
| Efficiency | |
| Height | |
| Industrial Grade | |
| Length | |
| Medical Grade | |
| Military Grade | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Output Voltage | |
| Power (Watts) | |
| SVHC Present | |
| Standard Number | |
| Storage Temperature | |
| Type | |
| Voltage | |
| Weight | |
| Width |
The Aimtec AME2-15SJZ-ST is a 2 Watt AC/DC converter designed for ITE (Commercial) applications. It offers a single 15V output with a maximum current of 133mA and an efficiency of 76% at full load.
This converter operates with an input voltage range of 85-305 VAC or 120-430 VDC. It provides 3000 VAC of I/O isolation and features auto-recovery for over-current and short-circuit protection. The operating temperature range is -25°C to +70°C.
Designed for chassis mounting, the AME2-15SJZ-ST has dimensions of 75.9mm x 31.5mm x 26.9mm. It meets safety standards including IEC/EN/UL 60950-1 and is approved by cURus. The unit also complies with EN55022 Class B for emissions.
The output voltage is 15V.
The maximum output current is 133 mA.
The power rating is 2W.
The typical efficiency is 76%.
The operating temperature range is -25°C to +70°C.
It uses chassis mount.
It complies with IEC/EN/UL 60950-1 and has cURus approval.
