The Aimtec AME15-48SJZ-ST is a 15 Watt AC-DC converter designed for reliable power conversion. It operates with an input voltage range of 85-305 VAC or 100-430 VDC, providing a stable 48V output at a maximum current of 0.32A.
Key electrical specifications include a typical efficiency of 85%, line regulation of ±0.5%, and load regulation of ±1%. The converter offers 3000 VAC isolation between input and output and 2000 VAC isolation to ground. It also features over-current protection, over-voltage protection, and short-circuit protection with auto-recovery.
Designed for industrial and commercial applications (ITE), this converter has a chassis mount type and an enclosed package. It operates within a temperature range of -40°C to 70°C with derating and has a maximum case temperature of 100°C. The dimensions for the screw terminal bottom plate version are 96.1mm x 54.0mm x 31.0mm.
This series offers features such as low ripple and noise, and a MTBF of over 300,000 hours.
The output voltage is 48V.
The maximum output power is 15W.
The input voltage range is 85-305 VAC or 100-430 VDC.
The typical efficiency is 85%.
The operating temperature range is -40°C to 70°C (With Derating).
It uses chassis mount.
The isolation voltage is 3000 VAC from input to output and 2000 VAC from input to ground.
