The Aimtec AME15-15S277VZ-ST is an enclosed AC-DC power supply module designed for various applications. It offers a 15W output power with a regulated 15V output voltage and a maximum output current of 1A.
The module accepts a wide universal input voltage range of 85-305VAC, making it suitable for global use. It provides a high isolation voltage of 4000VAC for enhanced reliability and system safety. The operating temperature range is from -40°C to 85°C, with full power available up to 55°C.
Key electrical specifications include an efficiency of 80% at 230VAC, typical ripple and noise of 50mV(p-p), and line and load regulation of ±0.5% and ±1% respectively. It also features output short circuit, over-current, and over-voltage protection.
Designed for easy integration, this converter has a chassis mount type and dimensions of 96.0mm x 54.1mm x 31.0mm. It is approved by cURus and complies with standard 62368-1, making it suitable for ITE (Commercial) applications.
The nominal output voltage is 15V.
The input voltage range is 85-305VAC.
The power rating is 15W.
The isolation voltage is 4000VAC.
The operating temperature range is -40°C to 85°C.
Yes, it includes output short circuit protection, output over-current protection, and output over-voltage protection.
