The Aimtec AME10-9SBJZ is a 10 Watt AC-DC converter designed for various applications. It operates with a wide input voltage range from 90 to 528 VAC or 100 to 745 VDC, making it versatile for global use.
This converter provides a single 9V output with a maximum current of 1.1A. Key electrical specifications include a typical efficiency of 78% at 230 VAC, a line regulation of ±0.5%, and a load regulation of ±1.0%. The ripple and noise are kept to a maximum of 150 mV p-p.
Designed for reliability, the AME10-9SBJZ includes over-current and over-voltage protection, along with continuous short circuit protection. It offers an I/O isolation voltage of 4000 VAC and operates within a temperature range of -40°C to +70°C.
The unit is enclosed and designed for Through Hole mounting, with dimensions of 62.0mm x 45.0mm x 30.0mm. It is suitable for ITE (Commercial) applications and carries CE approval.
The input voltage range is 90-528 VAC (47-63 Hz) or 100-745 VDC.
The package is a 4-DIP through-hole module.
The operating temperature range is -40°C to +70°C.
Output voltage is 9V DC with maximum current of 1.1A and maximum power of 10W.
Typical efficiency is 78% at 230 VAC.
It includes over current protection (130-400% of Iout), over voltage protection (15V clamp), and continuous short circuit protection with hiccup auto recovery.
Input to output isolation is 4000 VAC for 60 seconds.
