The Aimtec AME10-3.3SBJZ is a 10 Watt series AC-DC converter designed for various applications. This specific model provides a 3.3V output voltage and can deliver up to 2A of current, with a maximum output power of 6.6W. It accepts a wide universal input voltage range of 90-528 VAC or 100-745 VDC.
Key features include an efficiency of 72% at 230 VAC, line and load regulation of ±0.5% and ±1.0% respectively, and a ripple and noise level of 150mV p-p. The converter offers robust protection features such as over-current protection (130-400% of Iout) and over-voltage protection. It is designed for through-hole mounting and comes in a 4-DIP module package.
The operating temperature range is -40°C to +70°C with derating, and it has a high isolation voltage of 4000 VAC. The unit is Class II power supply compliant. Optional screw terminal bottom plates or DIN Rail screw terminal bottom plates are available by adding the suffix '-ST' or '-STD' respectively.
The AME10-3.3SBJZ has an output voltage of 3.3V.
The maximum output current for the AME10-3.3SBJZ is 2A.
The AME10-3.3SBJZ has a maximum output power of 6.6W.
The input voltage range for the AME10-3.3SBJZ is 90-528 VAC or 100-745 VDC.
The operating temperature range for the AME10-3.3SBJZ is -40°C to +70°C, with derating.
The AME10-3.3SBJZ is designed for Through Hole mounting.
