| Category | |
| Manufacturer Name | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Height | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Output Voltage | |
| Power (Watts) | |
| SVHC Present | |
| Standard Number | |
| Storage Temperature | |
| Temperature Coefficient | |
| Type | |
| Voltage | |
| Width |
The Aimtec AME10-24SBJZ-ST is a 10 Watt AC-DC converter designed for versatile power supply applications. It features a single 24V output and accepts a broad input voltage range of 90-528 VAC or 100-745 VDC, making it suitable for global use.
Key electrical specifications include a maximum output current of 0.45A, an efficiency of up to 82% at 230 VAC, and a hold-up time of 35ms at 230 VAC. The converter offers robust protection features such as over-current protection (130-400% of Iout) and over-voltage protection, with a continuous short circuit protection.
Designed for reliability, it provides 4000 VAC input-to-output isolation and operates within an ambient temperature range of -40°C to +70°C. The unit is Class II power supply compliant. Its dimensions are 96.0mm x 54.1mm x 38.6mm, and it is suitable for PCB mounting, with an optional screw terminal bottom plate available.
This converter is ideal for industrial, medical, and automation applications requiring a stable and efficient power solution. Its wide input range and protective features ensure dependable operation in various environments.
The output voltage is 24V.
The input voltage range is 90-528 VAC or 100-745 VDC.
The maximum output power is 10W.
The efficiency is typically 82%.
The operating temperature range is -40°C to +70°C.
It offers Class II protection, over-current protection, over-voltage protection, and short circuit protection.
