| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
10 pcs
|
10 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Height | |
| Input Voltage Range (AC) | |
| Input Voltage Range (DC) | |
| Length | |
| Maximum Output Power | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Output Current | |
| Package / Case | |
| Power (Watts) | |
| Storage Temperature | |
| Temperature Coefficient | |
| Type | |
| Voltage | |
| Width |
The Aimtec AME10-24SBJZ is a 10-watt AC/DC converter from the AME10-BJZ series, delivering a regulated 24V output at up to 450mA. It accepts a universal input range of 90-528VAC (47-63Hz) or 100-745VDC, making it suitable for global applications. The converter achieves 82% typical efficiency and features a no-load power consumption of 0.75W.
This enclosed module is designed for through-hole mounting in a 4-DIP package measuring 62.0 x 45.0 x 30.0 mm. It includes comprehensive protection features: over-current (130-400% of Iout), over-voltage (30VDC clamp), and continuous short-circuit protection with hiccup mode and auto recovery. The operating temperature range is -40°C to +70°C with derating, and cooling is by free air convection.
The AME10-24SBJZ is suitable for commercial ITE (Information Technology Equipment) applications. It provides 4000VAC input-to-output isolation and is rated as Class II (no earth ground required). The plastic case meets UL 94V-0 flammability rating. Output specifications include ±2% voltage accuracy, ±0.5% line regulation, and ±1.0% load regulation, with ripple and noise of 150mV p-p.
The input voltage range is 90-528VAC (47-63Hz) or 100-745VDC.
The package type is a 4-DIP module.
-40°C to +70°C with derating.
The part is listed as RoHS3 compliant, but this is unverified from the datasheet.
It includes over-current protection (130-400% of Iout), over-voltage protection (30VDC), and continuous short-circuit protection with hiccup mode and auto recovery.
Typical efficiency is 82%.
4000VAC input-to-output isolation.
