| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Cord Length | |
| Current | |
| Efficiency | |
| Form | |
| Input Connector | |
| Input Type | |
| Input Voltage | |
| Mounting Type | |
| No Load Power Consumption | |
| Operating Temperature | |
| Output Connector | |
| Output Current | |
| Output Voltage | |
| Power (Watts) | |
| Region Utilized | |
| Standard Number | |
| Voltage |
This Aimtec AMA24EU1-050300Y-1.2M is an AC/DC wall mount adapter designed for commercial ITE applications. It operates with an input voltage range of 90 to 264 VAC and delivers a stable 5V output at a maximum current of 3A, providing a total power of 15W.
The adapter features a fixed blade input type and a CEE 7/16 input connector, suitable for European power outlets. The output is delivered via a USB Micro connector with a cord length of 1.50 meters. It is designed with a Class II wall mount form factor.
Compliance is ensured with CE and UL certifications, adhering to standards 60950-1 and 62368-1. The unit boasts Level VI efficiency and a low no-load power consumption of 100mW maximum. Operating temperatures range from 0°C to 40°C. The dimensions are 72.0mm x 34.0mm x 88.0mm.
The adapter provides a 5V output at a maximum current of 3A.
The adapter has a power rating of 15W.
The input voltage range is 90 to 264 VAC.
The adapter meets Level VI efficiency standards.
The operating temperature range is 0°C to 40°C.
The adapter uses a USB Micro output connector.
The dimensions are 72.0mm x 34.0mm x 88.0mm.
