| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Cord Length | |
| Current | |
| Efficiency | |
| Form | |
| Industrial Grade | |
| Input Type | |
| Input Voltage | |
| No Load Power Consumption | |
| Operating Temperature | |
| Output Connector | |
| Output Current | |
| Output Voltage | |
| Polarization | |
| Power (Watts) | |
| Region Utilized | |
| SVHC Present | |
| Standard Number | |
| Voltage |
The Aimtec AMA24AK2-240075Y is a versatile AC/DC wall mount adapter designed for commercial ITE applications. This adapter delivers 18 watts of power with a stable 12V output and a maximum current of 1.5A.
It operates within a wide input voltage range of 90 to 264 VAC and features a fixed blade input type. The adapter meets Level VI efficiency standards, ensuring optimal energy usage. Its output is delivered via a locking barrel plug connector measuring 2.5mm I.D. x 5.5mm O.D. x 9.5mm, with a cord length of 60.2 inches (1.50m).
The operating temperature range is from 0°C to 40°C, making it suitable for various environments. Compliance is certified by CE and UL standards, including UL 60950-1 and 62368-1. The adapter is RoHS3 compliant and has an MSL rating of 1.
The adapter provides a 12V output voltage and a maximum current of 1.5A.
This adapter has a power rating of 18W.
The adapter accepts an input voltage range of 90 to 264 VAC.
The adapter meets Level VI efficiency standards.
The operating temperature range is from 0°C to 40°C.
It uses a locking barrel plug connector with dimensions 2.5mm I.D. x 5.5mm O.D. x 9.5mm.
It complies with CE, UL 60950-1, and UL 62368-1 standards.
