The Aimtec AM5T-2405DZ is an isolated DC-DC converter module from the AM5T-Z series. It delivers dual regulated outputs of +5V and -5V, each rated at 500mA, for a total output power of 5W. The converter accepts a wide 18-36V DC input (24V nominal) and provides 1500VDC input-to-output isolation.
This through-hole module is housed in a standard 24-DIP package measuring 31.8mm x 20.3mm x 10.2mm. Typical efficiency is 78%. Features include remote on/off control and remote sense capability. The operating temperature range is -40°C to +85°C, making it suitable for commercial ITE applications.
The AM5T-2405DZ is designed for board-mount power architectures requiring a clean bipolar supply from a single unregulated DC bus. Its compact DIP footprint and through-hole mounting simplify prototyping and production assembly.
| Qty | Low | High |
|---|---|---|
| 1+ | $21.25 | $21.25 |
| 5+ | $20.51 | $20.51 |
| 10+ | $20.15 | $20.15 |
| 20+ | $19.81 | $19.81 |
| 40+ | $19.48 | $19.48 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The input voltage range is 18V to 36V DC.
The converter provides +5V at 500mA and -5V at 500mA.
The isolation voltage is 1500VDC.
The operating temperature range is -40°C to +85°C.
It comes in a through-hole 24-DIP module.
Yes, it is listed as RoHS3 compliant.
Typical efficiency is 78%.
