The Aimtec AM50E-2415SVZ-STD is a 50W enclosed DC-DC converter designed for industrial applications. It operates with an input voltage range of 18-36VDC and provides a regulated 15V output at up to 3.333A.
Key electrical specifications include a high efficiency of 91% at full load and an isolation voltage of 1500VDC. The converter is built to meet EN62368 standard requirements and includes protections such as input under-voltage, over-current, and over-voltage.
This model features a chassis mount type and an enclosed package, with dimensions of 75.9mm x 31.5mm x 25.9mm. It operates reliably across an ultra-wide temperature range of -40°C to +105°C, making it suitable for demanding environments. Applications include industrial instrumentation, telecom, and lighting equipment.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The input voltage range is 18VDC to 36VDC.
The converter provides a regulated 15V output at a maximum current of 3.333A.
This DC-DC converter has a power rating of 50W.
The operating temperature range is -40°C to 105°C.
It offers an isolation voltage of 1500VDC between input and output.
This converter uses a chassis mount type.
Yes, it meets the EN62368-1 standard.
