| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
77 pcs
|
77 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Capacitive Load (Max) | |
| Current | |
| Current - Output (Max) | |
| Efficiency | |
| Height | |
| Isolation Voltage | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Package / Case | |
| Power (Watts) | |
| Size / Dimension | |
| Type | |
| Voltage | |
| Voltage - Input (Max) | |
| Voltage - Input (Min) | |
| Voltage - Output 1 | |
| Width |
The Aimtec AM4T-4805SZ is a 4-watt isolated DC-DC converter module designed for commercial ITE (Information Technology Equipment) applications. This single-output converter provides a regulated 5V output at 800mA from a wide input voltage range of 36V to 72V.
Key electrical specifications include an 80% typical efficiency and a maximum capacitive load of 1000µF. The module offers 1500VDC input-to-output isolation, ensuring reliable performance in systems requiring galvanic isolation. The converter includes continuous short circuit protection.
The AM4T-4805SZ is housed in a low-profile metal 24-DIP (Dual In-line Package) with dimensions of 1.25" L x 0.80" W x 0.40" H (31.8mm x 20.3mm x 10.2mm). It features through-hole mounting for secure attachment to PCBs and is pin-compatible with multiple industry-standard manufacturers. The operating temperature range is -40°C to 85°C, making it suitable for demanding environments.
| Qty | Low | High |
|---|---|---|
| 1+ | $19.13 | $19.13 |
| 5+ | $18.46 | $18.46 |
| 10+ | $18.14 | $18.14 |
| 20+ | $17.84 | $17.84 |
| 40+ | $17.54 | $17.54 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The input voltage range is 36V to 72V.
It provides a single 5V output with a maximum current of 800mA, for a total power of 4W.
The operating temperature range is -40°C to 85°C.
The part is listed as RoHS Compliant (RoHS3).
The package is a 24-DIP (Dual In-line Package) module, with through-hole mounting.
Yes, it provides 1500VDC input to output isolation.
The typical efficiency is 80%.
