| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
2,247 pcs
|
2247 pcs | On Request | 1 | On Request | On Request | 1530+ | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Height | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Power (Watts) | |
| Termination Style | |
| Type | |
| Voltage | |
| Width |
The Aimtec AM2D-1215DH52Z is an isolated DC-DC converter module delivering dual regulated outputs of +15V and -15V, each capable of 67mA, for a total output power of 2W. It operates from a nominal 12V input with a range of 10.8V to 13.2V.
This converter offers high isolation of 5200VDC, making it suitable for applications requiring galvanic isolation. Typical efficiency is 82%, and it operates over a wide temperature range of -40°C to +85°C, suitable for commercial ITE applications.
The module is housed in a 7-pin SIP (Single In-line Package) with through-hole mounting, measuring 19.5mm x 6.0mm x 10.0mm. It is RoHS3 compliant and CE approved.
| Qty | Low | High |
|---|---|---|
| 1+ | $7.81 | $7.81 |
| 5+ | $7.54 | $7.54 |
| 10+ | $7.41 | $7.41 |
| 20+ | $7.28 | $7.28 |
| 40+ | $7.16 | $7.16 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The converter provides dual outputs: +15V and -15V.
The input voltage range is 10.8V to 13.2V.
Each output can deliver 67mA.
The isolation voltage is 5200VDC.
The operating temperature range is -40°C to +85°C.
It is available in a 7-SIP Module with through-hole mounting.
Yes, it is listed as RoHS3 compliant (unverified).
