| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
59,888 pcs
|
59888 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| AEC Qualified | |
| Applications | |
| Approval Agency | |
| Automotive Grade | |
| Current | |
| Efficiency | |
| Halogen Free | |
| Height | |
| Industrial Grade | |
| Lead Spacing | |
| Lead Style | |
| Length | |
| Medical Grade | |
| Military Grade | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Package / Case | |
| Power (Watts) | |
| SVHC Present | |
| Standard Number | |
| Storage Temperature | |
| Tape & Reel | |
| Type | |
| Voltage | |
| Width |
The AM1DS-2415SH30JZ is a 1W isolated DC/DC converter module from Aimtec. It is designed for ITE (commercial) applications and provides a single output with 67mA current capability. The converter operates from a minimum input voltage of 21.6V and achieves 81% efficiency.
This through-hole mounted module comes in a compact 7-SIP package measuring 19.7mm x 6.0mm x 10.2mm. It is rated for an operating temperature range of -40°C to 105°C, making it suitable for a variety of environments. The module is certified to safety standard 62368-1 and carries cURus approval.
The isolated design ensures galvanic isolation between input and output, which is critical for noise reduction and safety in sensitive electronic systems. With its small footprint and high efficiency, the AM1DS-2415SH30JZ is well-suited for space-constrained board-level power conversion needs.
The minimum input voltage is 21.6V.
The output power is 1W.
The output current is 67mA.
The efficiency is 81%.
The operating temperature range is -40°C to 105°C.
It is available in a 7-SIP Module package.
Yes, it is listed as RoHS3 Compliant, but this is unverified.
