| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
7 pcs
|
7 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Current - Output (Max) | |
| Efficiency | |
| Height | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Package / Case | |
| Power (Watts) | |
| SVHC Present | |
| Type | |
| Voltage | |
| Voltage - Input (Min) | |
| Voltage - Output 1 | |
| Width |
The Aimtec AM1DR-1212S-NZ is an isolated DC-DC converter module designed for commercial ITE applications. It delivers a regulated 12V output with a maximum output current of 83mA, providing up to 1W of output power. The converter operates with an input voltage minimum of 11.4V (typical for 12V input systems) and features a typical efficiency of 70%.
This isolated module ensures safe operation in systems requiring galvanic isolation. It is rated for an operating temperature range of -40°C to 85°C, making it suitable for industrial environments. The converter is approved by cULus and cURus, indicating compliance with North American safety standards.
The AM1DR-1212S-NZ is housed in a compact 7-SIP (Single In-line Package) with through-hole mounting for easy integration on PCBs. Its dimensions are 19.6mm x 6.1mm x 10.2mm (0.77" x 0.24" x 0.40"). The RoHS3 and REACH compliance status is noted, though unverified. Note: The manufacturer has issued an End-of-Life notice for this series, with obsolescence date of December 30, 2022, so availability may be limited.
Through-hole 7-SIP module.
-40°C to 85°C.
Listed as RoHS3 compliant (unverified).
12V.
83mA.
1W.
70%.
