The Aimtec AM1D-2405DZ is an isolated DC-DC converter module designed for commercial ITE applications. It delivers dual regulated outputs of +5V and -5V, each capable of supplying 100mA, for a total output power of 1W. The module accepts a nominal 24V input with a range of 21.6V to 26.4V.
This converter features 1000V input-to-output isolation and achieves up to 74% efficiency. It is housed in a compact 7-SIP (Single In-line Package) with through-hole mounting, measuring 19.5mm x 6.0mm x 10.0mm. The operating temperature range spans -40°C to +85°C, making it suitable for industrial environments.
The AM1D-2405DZ is ideal for generating a bipolar supply rail from a single unregulated input, commonly used to power op-amps, sensors, and other analog circuits requiring a symmetric voltage. Its isolated design helps reduce ground loops and noise coupling in sensitive systems.
| Qty | Low | High |
|---|---|---|
| 1+ | $4.43 | $4.43 |
| 5+ | $4.27 | $4.27 |
| 10+ | $4.20 | $4.20 |
| 20+ | $4.13 | $4.13 |
| 40+ | $4.06 | $4.06 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The input voltage range is 21.6V to 26.4V.
It provides +5V at 100mA and -5V at 100mA.
The operating temperature range is -40°C to +85°C.
It comes in a 7-SIP (Single In-line Package) module with through-hole mounting.
RoHS compliance is listed as RoHS3 compliant, but this is unverified and low confidence.
