AM10CW-2412D-NZ-ST
Aimtec
The Aimtec AM10CW-2412D-NZ-ST is an enclosed DC DC converter with a power rating of 9.8W. It features chassis mounting and an efficiency of 87%.
| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Height | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Power (Watts) | |
| Standard Number | |
| Type | |
| Voltage | |
| Width |
The Aimtec AM10CW-4812D-NZ-ST is an enclosed DC DC converter designed for ITE (Commercial) applications. It provides dual outputs of +12V and -12V, each capable of delivering up to 410mA, for a total power output of 9.8W.
This converter accepts a wide input voltage range from 18V to 75V, with a maximum input of 75V. It boasts an efficiency of 87% and features 1.5 kV of isolation voltage. The operating temperature range is -40°C to 71°C, with derating applied.
Designed for easy integration, the AM10CW-4812D-NZ-ST features a chassis mount type. Its dimensions are 31.5mm x 76.0mm x 21.2mm (1.24" L x 2.99" W x 0.84" H). The unit complies with standard number 60950-1 and is approved by cURus.
Environmental compliance includes RoHS3 status and an MSL of 1. The HTSUS code is 8504.40.9580.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The input voltage range is from 18V to 75V.
The converter provides output voltages of +12V and -12V.
The efficiency is 87%.
It complies with IEC 60950-1 safety standard.
The maximum operating temperature is 71°C with derating.
The isolation voltage is 1.5 kV.
Yes, it is RoHS3 compliant.
