| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Dimensions | |
| Efficiency | |
| Height | |
| Input Voltage | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Output Current | |
| Output Power | |
| Output Voltage | |
| Power (Watts) | |
| Standard Number | |
| Type | |
| Voltage | |
| Width |
This Aimtec AM10CW-2415S-NZ-ST is a 10W DC DC converter designed for ITE (Commercial) applications. It features a single 15V output with a maximum current of 0.66A, powered by a wide input voltage range of 9-36V.
The converter boasts an efficiency of 87% and can handle a maximum capacitive load of 330µF. Its operating temperature range is -40°C to 85°C, making it suitable for various environmental conditions. The unit is enclosed and designed for screw terminal DIN rail mounting.
Key specifications include isolation voltage of 1.5kV and compliance with standard 60950-1, carrying cURus approval. The dimensions are 31.5mm x 76.0mm x 25.7mm, with a product weight of 55g.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The output voltage is 15V.
The input voltage range is 9-36V.
The maximum output current is 0.66A.
The power rating is 10W.
The efficiency is 87%.
The operating temperature range is -40°C to 85°C.
It is mounted using screw terminals on a DIN rail.
