| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Height | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Power (Watts) | |
| Standard Number | |
| Type | |
| Voltage | |
| Width |
This Aimtec AM10CW-2409D-NZ-ST is an enclosed DC DC converter designed for ITE (Commercial) applications. It features dual outputs of +9V and -9V, each capable of delivering up to 1A, for a total power output of 10W. The converter accepts an input voltage range from 9V to 36V and boasts an efficiency of 86%.
With a robust chassis mount design, this unit measures 31.5mm x 76.0mm x 21.2mm. It offers 1.5kV of isolation voltage, ensuring safety and reliability in various systems. The operating temperature range is -40°C to 71°C with derating. Compliance is indicated by cURus approval and adherence to standard 60950-1.
Key electrical specifications include a 9V to 36V input, dual -9V and 9V outputs, and a maximum output current of 1A per channel. The 10W power rating and 86% efficiency make it suitable for demanding power conversion tasks. The enclosed type and chassis mount facilitate integration into existing equipment.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The input voltage range is 9V to 36V.
It provides dual outputs of +9V and -9V, each with a maximum current of 1A.
The power rating is 10W.
The operating temperature is -40°C to 71°C with derating.
It uses chassis mount.
