| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Height | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Output Current | |
| Output Voltage | |
| Power (Watts) | |
| Standard Number | |
| Tape & Reel | |
| Type | |
| Voltage | |
| Width |
This Aimtec AM10CW-2403S-NZ-ST is a DC/DC DIN RAIL SUPPLY offering 10W of power and a 3.3V output voltage. It features a wide input voltage range from 9V to 36V DC and provides an output current of up to 2.4A. The converter boasts an efficiency of 79% and an isolation voltage of 1.5 kV.
Designed for ITE (Commercial) applications, this unit operates within a temperature range of -40°C to 85°C. Its compact dimensions of 31.5mm x 76.0mm x 25.7mm make it suitable for various installations. The mounting type is chassis mount, and it comes in bulk packaging.
Key specifications include a standard number of 60950-1 and cURus approval agency. The ECCN is EAR99, and it is RoHS3 Compliant with an MSL of 1 Unlimited.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The output voltage is 3.3V.
The maximum output current is 2.4A.
The power rating is 10W.
The efficiency is 79%.
The operating temperature range is -40°C to 85°C.
The dimensions are 31.5mm x 76.0mm x 25.7mm.
Yes, it is RoHS3 Compliant.
