AJM-24S12 The MINMAX AJM-24S12 is a 24W AC-DC power module with a 12VDC output and 2A current rating. It features a universal 85-264VAC input and operates across a wide temperature range.
Mfr Part #:

AJM-24S12

Available from 1 distributors
Mfr Name: MINM
MINM
The MINMAX AJM-24S12 is a 24W AC-DC power module with a 12VDC output and 2A current rating. It features a universal 85-264VAC input and operates across a wide temperature range.
✓ Total Stock: 5 pcs
$ Price Range: $1.70

AJM-24S12 Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Husky International Electronic ✓
Non-Authorised Inventory information
5 pcs
On Request
5 pcs On Request 1 On Request On Request N/A On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

AJM-24S12 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Input Frequency
Input Voltage
Mounting Type
Operating Temperature
Output Current
Output Voltage
Overload Protection
SVHC Present
View Similar Products (0)

AJM-24S12 Description

Short technical summary and product information.

The MINMAX AJM-24S12 is a fully encapsulated AC-DC power module from the AJM-24 series, designed for high performance in industrial and medical applications. It offers a 12VDC output with a 2A current capability, drawing power from a universal 85-264VAC input range.



This module operates reliably in challenging environments with an extended ambient temperature range of -40°C to +80°C. It provides 4000VAC I/O isolation with reinforced insulation, overload and short circuit protection, and meets stringent EMI Emission standards (EN 55011/32 Class B) and EMC Immunity standards (EN 61000-4-2,3,4,5,6,8,11).



Designed for PCB, chassis, or DIN-rail mounting, the AJM-24S12 is suitable for space-constrained applications. It holds multiple safety approvals including UL/cUL/IEC/EN 62368-1, UL508, and medical safety standards (2xMOPP per IEC/EN 60601-1), making it a versatile choice for global markets.

AJM-24S12 Quick Information

Product Type: AC-DC Power Module
Series: AJM-24
Canonical Name: AJM-24S12 AC-DC Power Module
Subcategory: DC DC Converters

AJM-24S12 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

AJM-24S12 Estimated Pricing

Qty Low High
1+ $1.70 $1.70

Estimated market price range - modelled values for guidance only, not live distributor offers.

AJM-24S12 Features

  • 24W AC-DC power module
  • 12VDC output at 2A
  • Universal 85-264VAC input
  • Wide -40°C to +80°C operating temperature
  • 4000VAC reinforced I/O isolation

AJM-24S12 Applications

  • Suitable for industrial applications
  • Designed for medical equipment
  • Ideal for space-constrained designs
  • Meets stringent EMI/EMC standards

AJM-24S12 FAQs

6 frequently asked questions generated from this part’s specifications.
What is the output voltage and current rating?

The AJM-24S12 provides a nominal 12VDC output capable of delivering up to 2000mA.

What input voltage ranges does this converter support?

It accepts 85 to 264 VAC or 120 to 370 VDC inputs across 47 to 440 Hz frequencies.

How much isolation voltage exists between the input and output?

The device features a reinforced insulation barrier providing a minimum 4000VAC I/O isolation voltage.

What protection features are included against electrical faults?

It includes overload protection above 105 percent with hiccup auto-recovery and continuous short-circuit protection with automatic recovery.

What mounting options are available for installation?

The converter supports PCB, chassis, and DIN-rail mounting configurations.

What is the allowable operating temperature range?

The unit operates reliably within an ambient temperature range of -40°C to +80°C.
