| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
1,312 pcs
|
1312 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| AEC Qualified | |
| Automotive Grade | |
| Features | |
| Halogen Free | |
| Industrial Grade | |
| Input Voltage | |
| Lead Style | |
| Medical Grade | |
| Military Grade | |
| Mounting Type | |
| Operating Temperature | |
| Output Current | |
| Output Voltage | |
| SVHC Present | |
| Storage Temperature | |
| Tape & Reel |
The AIC1722A-33GXTTR is a fixed output linear voltage regulator manufactured by AAIC. It provides a stable 3.3V output with a maximum current capability of 300mA. The device operates with an input voltage up to 8V and exhibits a typical voltage dropout of 470mV at 300mA.
Designed for surface mount applications, this regulator comes in a compact SOT-89-3 package. It operates across a wide temperature range from -40°C to +85°C, making it suitable for various environmental conditions. Key features include over-current protection and thermal shutdown, enhancing its reliability and safety in electronic circuits.
With its low standby current of 55uA, the AIC1722A-33GXTTR is an efficient choice for power management in battery-operated devices and other low-power applications. Its fixed output and protective features simplify circuit design and reduce component count.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.11 | $0.11 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The output voltage is fixed at 3.3V.
The maximum output current is 300mA.
The typical dropout voltage is 470mV at 300mA output current.
The operating temperature range is -40°C to +85°C.
It is available in a surface-mount SOT-89-3 package.
