The Analog Technologies AHV24V6KVC1MAW is a high voltage, non-isolated DC-DC converter designed for applications requiring precise voltage and current control. This enclosed unit features a chassis mount for secure installation.
Key electrical specifications include an input voltage of 24V, a 23V output voltage, and a 1mA output current. The converter operates with 70% efficiency and offers linear regulation for stable performance. It also includes a shutdown mode for power management, activated by a logic low signal on the SDN pin.
The physical dimensions are 104.5mm in length, 60.0mm in width, and 28.0mm in height. The operating temperature range is from -20°C to 50°C, making it suitable for various industrial environments.
This power module is designed for DC-DC conversion from low voltage to high voltage constant current power supply. Applications include X-ray machines, laser systems, spectral analysis, semiconductor manufacturing equipment, and particle accelerators. It is also used in capacitor charging and high voltage testing scenarios.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The output voltage is 23V.
The output current is 1mA.
The efficiency is 70%.
The operating temperature range is -20°C to 50°C.
It is a chassis mount type.
It provides linear regulation.
The input voltage is 24V.
