The XP Power AFM45US24C2 is an AC/DC desktop power supply delivering 48 watts of power with a 24V output. This unit is designed for international use, featuring an input voltage range of 80-264 VAC and an IEC 320-C8 polarized input connector. The output is provided via a standard barrel plug with 2.5mm inner diameter and 5.5mm outer diameter.
This power supply meets Energy Efficiency Level V standards and is compliant with CEC2008 & EISA2007 regulations. It holds IT & Medical approvals and is China Compulsory Certification (CCC) Qualified. The operating temperature range is 0°C to +60°C, with derating above +40°C. It also includes comprehensive protection features such as overvoltage, overload, and short circuit protection.
Key electrical specifications include a maximum input current of 1.2A at 115VAC, a hold-up time of 8ms minimum, and line/load regulation of ±1.0% and 2.5% maximum, respectively. The unit offers 4000 VAC isolation from input to output and 1500 VAC from input to ground. Its dimensions are 121.0mm x 50.0mm x 30.8mm.
The output voltage is 24V.
The power rating is 48W.
The input voltage range is 80-264 VAC.
It uses an IEC 320-C8 polarized input connector.
The dimensions are 121.0mm x 50.0mm x 30.8mm.
The operating temperature range is 0°C to +60°C.
Yes, it meets Energy Efficiency Level V.
