The Avago Technologies AFBR-709DMZ-IN3 is a compatible SFP+ SR transceiver, functioning as a dual-rate module for 1G/10G Ethernet and Fiber Channel applications. It is engineered for Multi-Mode Fiber (MMF) with OM3/OM4/OM5 compatibility, utilizing a Duplex LC/UPC connector.
This transceiver supports a maximum distance of 400 meters over OM4/OM5 fiber and 300 meters over OM3 fiber. It operates at an 850 nm wavelength with a supported data rate range of 1.25 Gbps to 11.32 Gbps. Key electrical specifications include a minimum transmitting power of -5 dBm, a maximum transmitting power of 0 dBm, and a receiver sensitivity of -11.1 dBm.
The module features DDM/DOM support for monitoring optical parameters and operates within a standard commercial temperature range of 0°C to 70°C. It requires a +3.3V single power supply. Compliance includes CE, Class 1 FDA and IEC60825-1 Laser Safety, RoHS, SFF-8431, and SFP MSA standards.
This specific variant is Intel-coded, designed for compatibility with Intel X520 and X710 server adapter families that auto-negotiate between 1 Gbps and 10 Gbps. It is an ideal choice for network infrastructure requiring flexible and reliable optical connectivity.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The maximum distance is 400 meters over OM4/OM5 Multi-Mode Fiber.
It uses a Duplex LC/UPC connector.
It supports data rates from 1.25 Gbps to 11.32 Gbps.
The operating temperature range is 0°C to 70°C.
Yes, DDM/DOM is supported for monitoring optical parameters.
The transmit wavelength is 850 nm.
The RoHS Status is listed as RoHS3 Compliant.
