AF1-B0-34-450-5G1-C The Littelfuse Inc. AF1-B0-34-450-5G1-C is a 1-pole, hydraulic-magnetic circuit breaker with a 5A current rating and a 277V voltage rating. It features a rocker actuator and panel mount.
Mfr Part #:

AF1-B0-34-450-5G1-C

Mfr Name: Littelfuse Inc.
Littelfuse Inc.
The Littelfuse Inc. AF1-B0-34-450-5G1-C is a 1-pole, hydraulic-magnetic circuit breaker with a 5A current rating and a 277V voltage rating. It features a rocker actuator and panel mount.
Stock on Request

AF1-B0-34-450-5G1-C Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Actuator Type
Approval Agency
Breaker Type
Current Rating
Current Rating (Amps)
Dimensions
Illumination
Mounting Type
Number of Poles
SVHC Present
Voltage Rating
View Similar Products (0)

AF1-B0-34-450-5G1-C Description

Short technical summary and product information.

This Littelfuse Inc. AF1-B0-34-450-5G1-C is a single-pole, hydraulic-magnetic circuit breaker designed for reliable circuit protection. It offers a current rating of 5A and a maximum operating voltage of 277V AC.



The breaker features a convenient rocker actuator for easy operation and a panel mount design for secure installation. Its hydraulic-magnetic trip mechanism ensures dependable performance across a range of operating temperatures.



This component is suitable for various electrical applications requiring robust overcurrent protection. The unit is specified with a 5A DC rating as well, indicating versatility for different system requirements.

AF1-B0-34-450-5G1-C Quick Information

Product Type: Circuit Breaker
Series: AF1
Canonical Name: Littelfuse Inc. AF1-B0-34-450-5G1-C Hydraulic-Magnetic Circuit Breaker
Subcategory: Hydraulic-Magnetic

AF1-B0-34-450-5G1-C Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

AF1-B0-34-450-5G1-C Features

  • 5A AC/DC current rating.
  • 277V AC maximum operating voltage.
  • Single pole hydraulic-magnetic breaker.
  • Rocker actuator for operation.
  • Panel mount design.

AF1-B0-34-450-5G1-C Applications

  • Provides overcurrent protection.
  • Suitable for panel installations.
  • Used in electrical control systems.
  • Offers hydraulic trip delay.

AF1-B0-34-450-5G1-C FAQs

7 frequently asked questions generated from this part’s specifications.
What is the current rating of the AF1-B0-34-450-5G1-C?

5A.

What is the voltage rating?

277VAC and 65VDC maximum.

What is the actuator type?

Rocker.

How many poles does this circuit breaker have?

1 pole.

What is the breaker type?

Magnetic (Hydraulic Delay).

What is the mounting type?

Panel Mount.

What are the dimensions of this breaker?

3/4" W x 2" H x 1-5/8" D.
