| Category | |
| Manufacturer Name | |
| Applications | |
| Cord Length | |
| Current | |
| Efficiency | |
| Form | |
| Height | |
| Input Connector | |
| Input Frequency | |
| Input Type | |
| Input Voltage | |
| Isolation | |
| Length | |
| No Load Power Consumption | |
| Operating Temperature | |
| Output Connector | |
| Overload Protection | |
| Polarization | |
| Power (Watts) | |
| Region Utilized | |
| Storage Temperature | |
| Temperature Coefficient | |
| Voltage | |
| Width |
The XP Power AEB36US05 is a versatile AC-DC desktop adapter delivering 20W of power with a stable 5V output. Designed for ITE (Commercial) applications, it features a universal input voltage range of 90-264 VAC, making it suitable for international use. The adapter boasts a compact form factor with dimensions of 110.0mm x 50.0mm x 20.0mm and utilizes a standard IEC 320-C8 input connector.
Key electrical specifications include a maximum input current of 1.00A for the AEB36 model, a no-load power consumption of less than 0.5W, and an efficiency rating of Level IV. It incorporates essential protections such as overvoltage, overload (hiccup mode), and short circuit protection. The output is delivered via a 2.5mm I.D. x 5.5mm O.D. barrel plug with a positive center polarization.
Compliance is met with EN55022 Level B emissions, EN61000-3-2 Class A harmonic currents, and safety approvals including EN62368-1 and UL62368. The operating temperature range is 0°C to 60°C. This adapter is RoHS3 compliant and has an MSL of 1.
The adapter accepts a universal input of 90-264 VAC at 47-63 Hz.
The operating temperature range is 0°C to 60°C, with linear derating above 40°C.
The adapter measures 110.0mm x 50.0mm x 20.0mm and is a desktop (Class II) form factor with a 48-inch output cord terminated in a right-angle barrel plug (2.5mm ID x 5.5mm OD).
The AEB36US05 meets Energy Efficiency Level IV.
Overvoltage protection (typical 125%, latching), overload protection (hiccup mode), and continuous short circuit protection.
It is approved to EN62368-1:2014+A11 and UL62368.
It meets EN55022 Level B for conducted and radiated emissions.
