| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
100,000 pcs
|
100000 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Coil Current | |
| Coil Resistance | |
| Coil Type | |
| Coil Voltage | |
| Contact Form | |
| Contact Material | |
| Contact Rating (Current) | |
| Lead Style | |
| Mounting Type | |
| Must Operate Voltage | |
| Operate Time | |
| Operating Temperature | |
| Relay Type | |
| Release Time | |
| Switching Voltage | |
| Termination Style |
This Panasonic Electronic Components ADZ12124V is a general purpose relay designed for high-current applications. It features a Single Pole Single Throw Normally Open (SPST-NO) contact configuration, capable of switching up to 120A.
The relay operates with a 24VDC coil voltage and has a latching, single coil type. Key electrical specifications include a coil current of 58.3 mA, a must operate voltage of 16.8 VDC, and a maximum switching voltage of 276VAC. The contact material is Silver Tin Oxide (AgSnO).
Designed for robust performance, the ADZ12124V has an operating temperature range of -40°C to 85°C. It is mounted via a chassis mount configuration and uses solder lug termination style. The operate and release times are both 20 ms.
This component is suitable for various industrial applications requiring reliable high-power switching.
| Qty | Low | High |
|---|---|---|
| 1+ | $2.00 | $2.00 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The contact rating is 120 A.
The coil voltage is 24VDC.
It has a SPST-NO (1 Form A) contact form.
The operating temperature range is -40°C to 85°C.
It is a chassis mount type.
The maximum switching voltage is 276VAC.
It is a Latching, Single Coil type.
