Mfr Part #:

ADV7181BBSTZ

Available from 1 distributors

Mfr Name: AD(RoHS)

The Analog Devices ADV7181BBSTZ is a NTSC/PAL/SECAM video decoder. It features 9-bit ADC/DAC resolution and 3 ADCs.

✓ Total Stock: 2 pcs

$ Price Range: $0.99

ADV7181BBSTZ Available from 1 distributor

✓ Authorised

✓ Non-Authorised

Distributor		Stock	Pricing	MOQ	PKG	Lead Time	Date Code	On Order Quantity	On Order Delivery
Bristol Electronics ✓ Non-Authorised Inventory information	2 pcs On Request	2 pcs	On Request	1	On Request	On Request	On Request	On Request	On Request

ADV7181BBSTZ Specifications Quick View

Most important parameters for selection – full specs in datasheet.

SELECT ALL

Category	New Products
Manufacturer Name	AD(RoHS)

View Similar Products (0)

ADV7181BBSTZ Description

Short technical summary and product information.

The Analog Devices ADV7181BBSTZ is an integrated circuit designed for video decoding applications. It supports NTSC, PAL, and SECAM video standards.

Key technical specifications include a 9-bit ADC/DAC resolution and three Analog-to-Digital Converters (ADCs). The device is housed in an LQFP package, measuring 10x10mm, and features 64 pins. It is rated for industrial temperature ranges.

This video decoder is suitable for various applications requiring video signal processing and conversion. Its design focuses on providing reliable performance in industrial automation and process automation systems.

ADV7181BBSTZ Quick Information

Product Type: Video Decoder

Series: ADV7181B

Canonical Name: ADV7181BBSTZ NTSC/PAL/SECAM Video Decoder

Subcategory: Encoders, Decoders, Converters

ADV7181BBSTZ Compliance

RoHS Status: RoHS Compliant

Moisture Sensitivity Level (MSL): 1 Unlimited

REACH Status: REACH Unaffected

ADV7181BBSTZ Estimated Pricing

Qty	Low	High
1+	$0.99	$0.99

Estimated market price range - modelled values for guidance only, not live distributor offers.

ADV7181BBSTZ Features

9-bit ADC resolution for moderate precision.
Three integrated ADCs for multi-channel input.
64-pin LQFP package for compact design.
Industrial screening level for reliability.
RoHS3 compliant and MSL 1 rated.

ADV7181BBSTZ Applications

Ideal for industrial analog-to-digital conversion.
Suitable for multi-channel sensor interfaces.
Used in video decoding applications.
Applicable in control systems requiring multiple ADCs.

ADV7181BBSTZ FAQs

4 frequently asked questions generated from this part’s specifications.

What is the ADC resolution?

9 bits.

How many ADCs are integrated?

What is the package type?

LQFP with 64 pins.

What is the screening level?

Industrial.
