| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
8,745 pcs
|
8745 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
6,756 pcs
|
6756 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
2,500 pcs
|
2500 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
325 pcs
|
325 pcs | On Request | 1 | On Request | On Request | 17+ | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Architecture | |
| Configuration | |
| Data Interface | |
| Input Type | |
| Mounting Type | |
| Number of A | |
| Number of Bits | |
| Number of Inputs | |
| Operating Temperature | |
| Ratio | |
| Reference Type | |
| SVHC Present | |
| Sampling Rate (Per Second) | |
| Supplier Device Package | |
| Voltage |
The ADS8344E is a 16-bit, 100-kSPS, 8-channel successive approximation register (SAR) analog-to-digital converter (ADC) from Texas Instruments. It accepts either 8 single-ended or 4 pseudo-differential input channels via an on-board multiplexer. The device uses an external voltage reference that can range from 500 mV to VCC, setting the analog input voltage range from 0 V to VREF.
Key electrical specifications include a typical signal-to-noise ratio (SNR) of 89 dB and a typical power consumption of 3.2 mW at a 100-kSPS throughput rate with a 5V supply. The ADC communicates over a standard SPI serial interface. It operates from a single analog and digital supply voltage between 2.7 V and 5.25 V.
The ADS8344E is housed in a 20-pin SSOP surface-mount package (20-SSOP, 0.154" width, 3.90 mm). It is specified for an operating temperature range of -40°C to +85°C. The device is pin-for-pin compatible with the ADS7844.
| Qty | Low | High |
|---|---|---|
| 1+ | $14.54 | $14.54 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The ADS8344E has a resolution of 16 bits.
The maximum sampling rate is 100 kSPS.
The ADS8344E has 8 input channels, configurable as 8 single-ended or 4 pseudo-differential inputs.
The operating temperature range is -40°C to +85°C.
The ADS8344E is available in a 20-SSOP surface-mount package.
The analog and digital supply voltage range is 2.7 V to 5.25 V.
Typical power consumption is 3.2 mW.
