The ADS5400HFS/EM is a 12-bit, 1 GSPS analog-to-digital converter (ADC) from Texas Instruments, designed for high-speed signal conversion. It operates from a 3.135V to 3.465V supply and provides LVDS-compatible digital outputs. The device features a pipelined architecture with a 7-clock cycle latency and includes an on-chip analog buffer to isolate the signal source from internal switching.
Key electrical specifications include a 2.1 GHz input bandwidth, typical SFDR of 65 dBc at 1.2 GHz, and SNR of 57 dBFS at 1.2 GHz. The differential input accepts a programmable 1.5 to 2 Vpp range. Total power dissipation is 2.2 W. The ADC also includes a temperature sensor and supports interleave-friendly internal adjustments for gain, phase, and offset.
The ADS5400HFS/EM is housed in a 100-CBQFP Exposed Pad surface-mount package (supplier package 100-CFP). It operates over the full military temperature range of -55°C to 125°C case temperature. The ceramic package allows operation without an external heatsink. This part is processed per internal QML class V assembly/test flow and is radiation-tolerant (50krad).
| Qty | Low | High |
|---|---|---|
| 1+ | $4,460.17 | $4,460.17 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The supply voltage range is 3.135V to 3.465V.
It is available in a 100-CBQFP Exposed Pad package (supplier package 100-CFP).
-55°C to 125°C.
It is listed as RoHS3 compliant, but this is unverified.
1 GSPS.
12 bits.
2.1 GHz typical.
