ADS1250U The ADS1250U from B&B Smartworx is a 20-bit analog-to-digital converter featuring a 25kHz data rate and differential inputs. It operates from a single +5V supply and is available in a 16-pin SOIC package.
Mfr Part #:

ADS1250U

Available from 1 distributors
Mfr Name: B&B Smartworx
B&B Smartworx
The ADS1250U from B&B Smartworx is a 20-bit analog-to-digital converter featuring a 25kHz data rate and differential inputs. It operates from a single +5V supply and is available in a 16-pin SOIC package.
✓ Total Stock: 80 pcs
$ Price Range: $2.01

ADS1250U Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Partservice ✓
Non-Authorised Inventory information
80 pcs
On Request
80 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

ADS1250U Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Data Rate
Inputs
Interface
Noise
Resolution
Storage Temperature
Supply Voltage
Tape & Reel
View Similar Products (0)

ADS1250U Description

Short technical summary and product information.

The ADS1250U is a precision, wide dynamic range, delta-sigma analog-to-digital converter from B&B Smartworx, offering 20-bit resolution. It operates from a single +5V supply and guarantees 20 bits of no missing code performance. The converter achieves an effective resolution of 18 bits with low noise (2.8ppm at PGA=1) for conversion rates up to 25kHz.



Key features include differential inputs, a programmable gain amplifier (PGA) with gain stages of 1, 2, 4, or 8 for enhanced dynamic range, and a flexible synchronous serial interface. The ADS1250U is designed for high-resolution measurement applications.



This component is housed in a 16-pin SOIC package and is supplied on a tape and reel. It is suitable for applications requiring precise analog-to-digital conversion.

ADS1250U Quick Information

Product Type: Analog-to-Digital Converter
Canonical Name: ADS1250U 20-Bit Data Acquisition System Analog-to-Digital Converter
Subcategory: Precision ADCs

ADS1250U Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

ADS1250U Estimated Pricing

Qty Low High
1+ $2.01 $2.01

Estimated market price range - modelled values for guidance only, not live distributor offers.

ADS1250U Features

  • 20-bit resolution with no missing codes.
  • Effective resolution of 18 bits at 25kHz.
  • Low noise performance at 2.8ppm.
  • Programmable gain amplifier stages available.
  • Operates from a single +5V supply.

ADS1250U Applications

  • High-resolution measurement applications.
  • Cardiac diagnostics systems.
  • Industrial process control.
  • Weigh scales and chromatography.
  • Portable instrumentation.

ADS1250U FAQs

5 frequently asked questions generated from this part’s specifications.
What is the resolution of the ADS1250U?

The ADS1250U offers 20-bit resolution with no missing codes.

What is the data rate for the ADS1250U?

The data rate for the ADS1250U is up to 25kHz.

What is the effective resolution of the ADS1250U at 25kHz?

The effective resolution is 18 bits with 2.8ppm of rms noise.

What supply voltage does the ADS1250U require?

The ADS1250U operates from a single +5V supply.

What package type is the ADS1250U available in?

The ADS1250U is available in a 16-pin SOIC package.
