ADP5054ACPZ-R7 The Analog Devices ADP5054ACPZ-R7 is a quad buck regulator offering a wide input voltage range and flexible output current capabilities. It features up to 4 outputs and can provide a single 12A output when channels are paralleled.
Mfr Part #:

ADP5054ACPZ-R7

Available from 2 distributors
Mfr Name: Analog Devices / Maxim Integrated
Analog Devices / Maxim Integrated
The Analog Devices ADP5054ACPZ-R7 is a quad buck regulator offering a wide input voltage range and flexible output current capabilities. It features up to 4 outputs and can provide a single 12A output when channels are paralleled.
✓ Total Stock: 2,802 pcs
$ Price Range: $0.75

ADP5054ACPZ-R7 Available from 2 distributors

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
PROSOFT ELECTRONICS ✓
Non-Authorised Inventory information
2,400 pcs
On Request
2400 pcs On Request 1 On Request On Request 22+ On Request On Request
Trace Tec ✓
Non-Authorised Inventory information
402 pcs
On Request
402 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

ADP5054ACPZ-R7 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Clock Sync
Control Features
Duty Cycle (Max)
Frequency
Function
Lead Style
Mounting Type
Number of Outputs
Operating Temperature
Operating Voltage
Output Configuration
Output Phases
Output Type
Supplier Device Package
Supplier Package
Synchronous Rectifier
Topology
Voltage
View Similar Products (0)

ADP5054ACPZ-R7 Description

Short technical summary and product information.

The ADP5054ACPZ-R7 from Analog Devices is an integrated quad buck regulator designed for demanding performance and space-constrained applications. It supports a wide input voltage range from 4.5V to 15.5V, eliminating the need for preregulators.



This device integrates four high-performance buck regulators. Channels 1 and 2 are programmable for 2A, 4A, or 6A output currents, and can be paralleled for a single 12A output. Channels 3 and 4 provide 2.5A synchronous buck regulation each, with the option to parallel them for a 5A output.



The ADP5054ACPZ-R7 operates with a switching frequency adjustable from 250 kHz to 2 MHz. It includes features such as precision enable, power-good flag, and frequency synchronization. The regulator is housed in a 48-lead, 7 mm × 7 mm LFCSP package, suitable for surface mounting.



Applications for this component include FPGA and processor systems, small cell base stations, security and surveillance equipment, and medical devices. It operates within a junctional temperature range of -40°C to +125°C.

ADP5054ACPZ-R7 Quick Information

Product Type: DC DC Switching Controller
Canonical Name: ADP5054ACPZ-R7 Quad Buck Regulator
Subcategory: DC DC Switching Controllers

ADP5054ACPZ-R7 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

ADP5054ACPZ-R7 Estimated Pricing

Qty Low High
1+ $0.75 $0.75

Estimated market price range - modelled values for guidance only, not live distributor offers.

ADP5054ACPZ-R7 Features

  • Quad buck regulator with flexible outputs.
  • Wide 4.5V to 15.5V input voltage range.
  • Programmable current for channels 1 & 2.
  • Paralleled channels for higher current outputs.
  • Adjustable switching frequency up to 2 MHz.

ADP5054ACPZ-R7 Applications

  • Ideal for FPGA and processor applications.
  • Suitable for small cell base stations.
  • Used in security and surveillance systems.
  • Applicable for medical device designs.

ADP5054ACPZ-R7 FAQs

7 frequently asked questions generated from this part’s specifications.
What is the input voltage range for the ADP5054ACPZ-R7?

The input voltage range is 4.5 V to 15.5 V.

How many outputs does the ADP5054ACPZ-R7 have?

The ADP5054ACPZ-R7 has 4 outputs.

What is the maximum output current for channels 1 and 2?

Channels 1 and 2 are programmable for 2 A, 4 A, or 6 A output currents.

What is the maximum output current for channels 3 and 4?

Channels 3 and 4 provide 2.5 A synchronous buck regulation.

What is the adjustable switching frequency range?

The switching frequency is adjustable from 250 kHz to 2 MHz.

What is the operating temperature range?

The operating junction temperature range is -40°C to +125°C.

What package is the ADP5054ACPZ-R7 supplied in?

It is supplied in a 48-lead, 7 mm × 7 mm LFCSP package.
