| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
25 pcs
|
25 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
6 pcs
|
6 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Body Width | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Material | |
| Current Rating | |
| Data Rate | |
| Features | |
| Height Above Board | |
| IPC Class | |
| Insulator Material | |
| Lead Spacing | |
| Lead Style | |
| Lead-Free Solderable | |
| Mated Stacking Heights | |
| Mounting Type | |
| Number of Positions | |
| Number of Rows | |
| Operating Temperature Range | |
| Pitch | |
| Plating | |
| Termination Style | |
| Voltage Rating |
The ADM6-30-01.5-L-4-2-A-TR is a 0.64mm (0.025") pitch high density array male connector from the Samtec AcceleRate HD series. It features 30 positions arranged in 4 rows, with a surface mount solder column termination. The connector uses the Edge Rate contact system for optimized signal integrity.
This connector delivers 64 Gbps PAM4 (32 Gbps NRZ) performance and is PCIe 6.0 capable. It is rated for 1.34 A per pin (4 pins powered) and 155 VAC / 219 VDC working voltage. The operating temperature range is -55°C to +125°C.
The insulator is black LCP, contacts are copper alloy with gold plating (10 µ" over 50 µ" Ni). The body width is 5 mm, with a mated stacking height of 5 mm. It includes a board guide feature and is lead-free solderable, IPC Class 3 compliant.
Packaging is tape and reel. This part is suitable for high-density mezzanine board-to-board connections in high-speed digital systems.
30 positions.
0.64mm (0.025").
1.34 A per pin (4 pins powered).
155 VAC / 219 VDC.
Surface mount.
-55°C to +125°C.
64 Gbps PAM4 (32 Gbps NRZ).
