ADG706BRUZ
Arrow Electronics
The ADG706BRUZ from Analog Devices is a 16-channel CMOS analog multiplexer. It features low on-resistance and operates from a single 1.8V to 5.5V supply.
| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
5,000 pcs
|
5000 pcs | On Request | 1 | On Request | On Request | 21+ | On Request | On Request | |
|
277 pcs
|
277 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
11 pcs
|
11 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Charge Injection | |
| Number of Circuits | |
| Operating Voltage |
The ADG706BRUZ is a low-voltage, CMOS analog multiplexer from Analog Devices Inc., designed for applications requiring efficient signal routing. This device functions as a single 16-to-1 multiplexer, controlled by 4-bit binary address lines.
Key electrical specifications include a typical ON resistance of 2.5 Ω and flatness of 0.5 Ω. It operates from a single supply voltage ranging from 1.8 V to 5.5 V or a dual supply of ±2.5 V. Leakage currents are as low as 100 pA, with switching times around 40 ns. The bandwidth is 25 MHz.
Designed for battery-powered systems and communication applications, the ADG706BRUZ offers low-power consumption and TTL/CMOS-compatible inputs. It exhibits break-before-make switching action, preventing momentary shorting when channels are switched. The device is housed in a compact 28-lead TSSOP package, suitable for space-constrained designs.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The typical ON resistance is 2.5 Ω.
It operates from a single supply of 1.8 V to 5.5 V or a dual supply of ±2.5 V.
The ADG706BRUZ is supplied in a 28-lead TSSOP package.
The switching time is a maximum of 32 ns and a typical of 16 ns.
The -3dB bandwidth is 25 MHz.
