The Cosel ADA600F-36-CT is a 36V, 10A AC/DC converter designed for ITE (Commercial) applications. It offers a power output of 360W, with a higher 594W rating when forced air cooling is utilized.
This enclosed converter features a universal input voltage range of 85-264 VAC and incorporates Power Factor Correction (PFC). Key electrical specifications include an efficiency of 87% at 200V input, a typical power factor of 0.98, and a hold-up time of 20ms. The output voltage is adjustable within the range of 33.0-41.0V, with a setting range of 35.0-37.0V.
Designed for robust performance, it includes overcurrent and overvoltage protection. The operating temperature range is -10°C to 71°C with derating. Mounting is via chassis, and the dimensions are 195.0mm x 127.0mm x 65.0mm.
Compliance includes CE, CSA, cURus, TUV, and UL approvals, adhering to standards like 60950-1 and 62368-1. It also meets EMI standards such as FCC-B and CISPR22-B, and complies with RoHS directives.
85-264 VAC.
36V at 10A (16.5A with forced air).
-10°C to 71°C with derating.
Enclosed, conformal coated, chassis mount.
Yes, 41-60V.
UL60950-1, C-UL (CSA60950-1), EN62368-1.
87% typical.
