| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Input Frequency | |
| Input Voltage | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Output Voltage | |
| Power (Watts) | |
| Ripple | |
| Standard Number | |
| Type | |
| Voltage | |
| Width |
The Cosel ADA600F-24 is an enclosed AC/DC converter with a 24V output voltage and a maximum output current of 15A under convection cooling, providing 360W of power. It supports a universal input voltage range of 85-264 VAC and features a power factor correction (PFC) for improved efficiency, rated at 86% typical at 200V input.
Designed for reliability, this converter operates within a temperature range of -10°C to 71°C with derating and includes overcurrent and overvoltage protection. Its robust construction and chassis mount type make it suitable for various industrial and commercial applications, including ITE (Information Technology Equipment).
Key specifications include a 3kV isolation voltage, a hold-up time of 20ms, and compliance with safety standards such as UL60950-1 and EN62368-1. The unit also meets EMI standards like FCC-B and CISPR22-B.
85-264 VAC.
24V.
-10°C to 71°C with derating.
Enclosed chassis mount, 195.0mm x 127.0mm x 65.0mm.
89% typical at 200VAC input and full load.
Overcurrent protection (works over 101% of peak current, auto recovery) and overvoltage protection (31-34.5V).
3kV.
