| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Input Voltage | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Output Voltage | |
| Power (Watts) | |
| Standard Number | |
| Tape & Reel | |
| Type | |
| Voltage | |
| Width |
The Cosel ADA1000F-30-U is an enclosed AC DC converter designed for ITE (Commercial) applications. It provides a stable 30V output voltage and can deliver up to 600W of power under convection cooling, or 1005W with forced air.
This power supply operates with a universal input voltage range of 85-264 VAC and includes Power Factor Correction (PFC) for improved efficiency, rated at 88% typical. Key electrical specifications include a maximum output current of 16.5A (forced air) and 11A (convection), with a hold-up time of 20ms. It also features overcurrent and overvoltage protection circuits.
The unit is designed for chassis mounting and operates within an ambient temperature range of -10°C to 71°C with derating. Safety approvals include CE, CSA, cURus, TUV, and UL, complying with standards such as IEC60950-1 and IEC62368-1. Optional features like remote ON/OFF and a fan unit are available.
The output voltage is 30V.
The maximum output power is 600W under convection cooling and 1005W with forced air.
The input voltage range is 85-264 VAC.
The operating temperature range is -10°C to 71°C with derating.
The dimensions are 280.0mm x 127.0mm x 75.0mm.
It has CE, CSA, cURus, TUV, and UL approvals.
Yes, it is RoHS3 Compliant.
