AD9777BSVZ 16-bit, 160 MSPS dual digital-to-analog converter with parallel interface. Features 11 µs settling time, -73 dBc SFDR, and operates from 3.1V to 3.5V supply.
Mfr Part #:

AD9777BSVZ

Available from 2 distributors
Mfr Name: Analog Devices / Maxim Integrated
Analog Devices / Maxim Integrated
16-bit, 160 MSPS dual digital-to-analog converter with parallel interface. Features 11 µs settling time, -73 dBc SFDR, and operates from 3.1V to 3.5V supply.
✓ Total Stock: 5,500 pcs

AD9777BSVZ Available from 2 distributors

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Components Technology Group, Inc. ✓
Non-Authorised Inventory information
4,789 pcs
On Request
4789 pcs On Request 1 On Request On Request On Request On Request On Request
Optech Co.,Limited ✓
Non-Authorised Inventory information
711 pcs
On Request
711 pcs On Request 1 On Request On Request 21+ On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

AD9777BSVZ Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Architecture
Data Interface
Differential Output
INL
Mounting Type
Number of Bits
Number of D
Operating Temperature
Output Type
Power Dissipation
Reference Type
Settling Time
Supplier Device Package
Voltage
View Similar Products (0)

AD9777BSVZ Description

Short technical summary and product information.

The AD9777BSVZ is a 16-bit, 160 MSPS interpolating dual DAC from Analog Devices. It features an oversampling interpolating architecture with selectable 2x/4x/8x interpolation filters. The device provides excellent AC performance with SFDR of -73 dBc at 2 MHz to 35 MHz. It includes a parallel data interface and supports both external and internal reference. The DAC operates from a single 3.3V supply with typical power dissipation of 1.2 W. It is designed for communications applications such as 3G, multicarrier GSM, and broadband wireless systems. The device is housed in an 80-lead TQFP with exposed pad for surface mount assembly. Operating temperature range is -40°C to 85°C.

AD9777BSVZ Quick Information

Product Type: Digital to Analog Converter (DAC)
Canonical Name: 16-Bit, 160 MSPS Interpolating Dual Digital-to-Analog Converter
Subcategory: Interpolating DAC

AD9777BSVZ Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

AD9777BSVZ Features

  • 16-bit resolution with 160 MSPS data rate.
  • Dual DAC with oversampling interpolating architecture.
  • Parallel data interface with selectable coding.
  • Excellent SFDR of -73 dBc at 2-35 MHz.
  • Surface mount 80-TQFP exposed pad package.

AD9777BSVZ Applications

  • Communications analog quadrature modulation.
  • 3G, multicarrier GSM, CDMA systems.
  • Broadband wireless and point-to-point microwave radios.
  • Instrumentation and ATE systems.

AD9777BSVZ FAQs

7 frequently asked questions generated from this part’s specifications.
What is the resolution of the AD9777BSVZ?

16 bits.

What is the maximum sampling rate?

160 MSPS.

What is the settling time?

11 µs typical.

What is the supply voltage range?

3.1V to 3.5V.

What is the operating temperature range?

-40°C to 85°C.

What package does it come in?

80-TQFP Exposed Pad (80-TQFP-EP 12x12).

Is it RoHS compliant?

RoHS3 compliant (unverified).
