AD9230BCPZ-250 Analog Devices AD9230BCPZ-250 is a 12-bit, 250 MSPS pipelined analog-to-digital converter with LVDS interface. It features a differential input, 1.8V supply, and 434 mW dissipation.
Mfr Part #:

AD9230BCPZ-250

Available from 3 distributors
Mfr Name: Analog Devices / Maxim Integrated
Analog Devices / Maxim Integrated
Analog Devices AD9230BCPZ-250 is a 12-bit, 250 MSPS pipelined analog-to-digital converter with LVDS interface. It features a differential input, 1.8V supply, and 434 mW dissipation.
✓ Total Stock: 12,623 pcs

AD9230BCPZ-250 Available from 3 distributors

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Optech Co.,Limited ✓
Non-Authorised Inventory information
7,620 pcs
On Request
7620 pcs On Request 1 On Request On Request 24+ On Request On Request
Components Technology Group, Inc. ✓
Non-Authorised Inventory information
5,000 pcs
On Request
5000 pcs On Request 1 On Request On Request On Request On Request On Request
Speed Components Ltd ✓
Non-Authorised Inventory information
3 pcs
On Request
3 pcs On Request 1 On Request On Request 09+ On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

AD9230BCPZ-250 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Architecture
Configuration
Contact Plating
Data Interface
Height
Input Capacitance
Input Type
Length
Mounting Type
Number of A
Number of Bits
Number of Inputs
Operating Temperature
Power Dissipation
Ratio
Reference Type
Sampling Rate (Per Second)
Supplier Device Package
Supply Current
Voltage
Width
View Similar Products (0)

AD9230BCPZ-250 Description

Short technical summary and product information.

The AD9230BCPZ-250 is a 12-bit monolithic sampling analog-to-digital converter from Analog Devices, optimized for high-speed data conversion at 250 MSPS. It achieves excellent dynamic performance with a typical SNR of 64.9 dBFS and SFDR of -79 dBc at 70 MHz input. The device features a pipelined architecture with integrated input buffer and track-and-hold, and operates from a single 1.8V supply, dissipating 434 mW in LVDS SDR mode. The ADC offers a programmable input voltage range of 1.0 V to 1.5 V, and supports differential or single-ended inputs. Output data can be selected as offset binary, twos complement, or Gray code via the serial port interface. The AD9230BCPZ-250 is housed in a 56-lead LFCSP EP package (8 mm × 8 mm) with surface mount mounting, and is specified for operation from -40°C to 85°C. It is RoHS3 compliant. Typical applications include wireless and wired broadband communications, cable reverse path, radar and satellite subsystems, and power amplifier linearization.

AD9230BCPZ-250 Quick Information

Product Type: Analog-to-Digital Converter (ADC)
Series: AD9230
Canonical Name: Analog Devices AD9230BCPZ-250 12-Bit 250 MSPS Analog-to-Digital Converter
Subcategory: Data Acquisition

AD9230BCPZ-250 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

AD9230BCPZ-250 Features

  • 12-bit resolution with 250 MSPS sampling rate.
  • Pipelined architecture with LVDS parallel interface.
  • Typical SNR of 64.9 dBFS and SFDR of -79 dBc.
  • Low power dissipation of 434 mW at 250 MSPS.
  • Programmable input voltage range from 1.0 V to 1.5 V.

AD9230BCPZ-250 Applications

  • Ideal for wireless and wired broadband communications.
  • Used in cable reverse path applications.
  • Suitable for radar and satellite subsystems.
  • Designed for power amplifier linearization.
  • Applied in communications test equipment.

AD9230BCPZ-250 FAQs

7 frequently asked questions generated from this part’s specifications.
What is the resolution of the AD9230BCPZ-250?

The ADC has a resolution of 12 bits.

What is the maximum sampling rate of the AD9230BCPZ-250?

The maximum sampling rate is 250 MSPS (mega-samples per second).

What is the supply voltage for the AD9230BCPZ-250?

The supply voltage is 1.8 V nominal, with a range of 1.7 V to 1.9 V.

What is the operating temperature range of the AD9230BCPZ-250?

The operating temperature range is -40°C to 85°C.

What is the package type of the AD9230BCPZ-250?

The device is packaged in a 56-lead LFCSP EP (8 mm × 8 mm) with surface mount mounting.

Is the AD9230BCPZ-250 RoHS compliant?

Yes, the device is RoHS3 compliant.

What is the typical power dissipation of the AD9230BCPZ-250?

Typical power dissipation is 434 mW at 250 MSPS in LVDS SDR mode.
